PyQT를 활용한 회사/차량 데이터 인터페이스 제작 - mpg.csv

PyQt.ui

0.00MB





PyQt.py

0.01MB

mpg.csv

0.01MB







import sys
import csv
from PyQt5.QtWidgets import *
from PyQt5 import uic
import matplotlib.pyplot as plt
from matplotlib.backends.backend_qt5agg import FigureCanvas as FigureCanvas
from matplotlib.figure import Figure

form_class = uic.loadUiType('./pyQt/ui/miniproject1.ui')[0]

class Class(QWidget, form_class):
    second_ui_instance = None

    def __init__(self):
        super().__init__()
        f = open('./pyQt/csv/mpg.csv', encoding='cp949')
        self.data = list(csv.reader(f))
        f.close()
        self.data.pop(0)
        self.setupUi(self)
        self.initUI()

        self.button.clicked.connect(self.btnClicked)
        self.createTable()
        self.create_combo_list1()
        self.create_combo_list2()
        self.Company.currentTextChanged.connect(self.create_combo_list2)
        self.button2.clicked.connect(self.open_graph)

    def initUI(self):
        self.setWindowTitle('자동차 정보')
        self.show()

    def createTable(self):
        self.tableWidget = QTableWidget(self)
        self.vLayout.addWidget(self.tableWidget)

    def updateTable(self, header, data):
        self.tableWidget.clear()

        n_row, n_col = len(data), len(header)
        self.tableWidget.setRowCount(n_row)
        self.tableWidget.setColumnCount(n_col)
        self.tableWidget.setHorizontalHeaderLabels(header)

        for row in range(n_row):
            for col in range(n_col):
                item = QTableWidgetItem(data[row][col])
                self.tableWidget.setItem(row, col, item)

    def btnClicked(self):
        header = ['회사명','모델','배기량','년도', '실린더 수','변속기','구동방식', '도시연비', '고속도로연비', '연료종류', '차종']
        self.new_data = []

        for i in range(len(self.data)):
            if (self.Company.currentText() == self.data[i][0] or self.Company.currentText() == 'All') and \
               (self.Models.currentText() == self.data[i][1] or self.Models.currentText() == 'All'):
                self.new_data.append(self.data[i])

        self.updateTable(header, self.new_data)

    def create_combo_list1(self):
        company_set = set(cnt[0] for cnt in self.data)
        self.Company.addItems(['All'] + list(company_set))

    def create_combo_list2(self):
        models = [cnt[1] for cnt in self.data if self.Company.currentText() == 'All' or self.Company.currentText() == cnt[0]]
        self.Models.clear()
        self.Models.addItem('All')
        self.Models.addItems(set(models))

    def open_graph(self):
        if not Class.second_ui_instance:
            Class.second_ui_instance = SecondUI(self.new_data)
            Class.second_ui_instance.show()

class SecondUI(QMainWindow):
    def __init__(self, new_data):
        super().__init__()
        self.new_data = new_data

        self.main_widget = QWidget()
        self.setCentralWidget(self.main_widget)

        self.layout = QGridLayout(self.main_widget)
        plt.rcParams['font.family'] ='Malgun Gothic'
        plt.rcParams['axes.unicode_minus'] =False

        canvas1 = FigureCanvas(Figure(figsize=(4, 3)))
        ax1 = canvas1.figure.subplots()
        self.create_graph(ax1, '연료 종류별 도시 연비 평균', '연료 종류', '도시 연비', 9, 7)
        self.layout.addWidget(canvas1, 0, 0)

        canvas2 = FigureCanvas(Figure(figsize=(4, 3)))
        ax2 = canvas2.figure.subplots()
        self.create_graph(ax2, '실린더 수별 도시 연비 평균', '실린더 수', '도시 연비', 4, 7)
        self.layout.addWidget(canvas2, 0, 1)

        canvas3 = FigureCanvas(Figure(figsize=(4, 3)))
        ax3 = canvas3.figure.subplots()
        self.create_graph(ax3, '연료 종류별 고속도로 연비 평균', '연료 종류', '고속도로 연비', 9, 8)
        self.layout.addWidget(canvas3, 1, 0)

        canvas4 = FigureCanvas(Figure(figsize=(4, 3)))
        ax4 = canvas4.figure.subplots()
        self.create_graph(ax4, '실린더 수별 고속도로 연비 평균', '실린더 수', '고속도로 연비', 4, 8)
        self.layout.addWidget(canvas4, 1, 1)

        self.setWindowTitle('실린더 / 연료종류 별 각종 연비 평균 그래프')
        self.setGeometry(400, 30, 1200, 1000)

    def closeEvent(self, event):
        Class.second_ui_instance = None
        super().closeEvent(event)

    def create_graph(self, ax, title, xlabel, ylabel, index1, index2):
        data = {}
        count = {}
        for i in self.new_data:
            if i[9] == 'r':
                i[9] = '일반유'
            elif i[9] == 'p':
                i[9] = '고급유'
            elif i[9] == 'e':
                i[9] = '에탄올 E85'
            elif i[9] == 'd':
                i[9] = '디젤'
            elif i[9] == 'c':
                i[9] = '천연가스'
            else:
                pass

            if i[index1] in data:
                data[i[index1]] += int(i[index2])
                count[i[index1]] += 1
            else:
                data[i[index1]] = int(i[index2])
                count[i[index1]] = 1

        sorted_keys = sorted(data.keys())

        cty = [value / count[key] for key, value in data.items()]

        bars = ax.bar(sorted_keys, cty)

        for bar, value in zip(bars, cty):
            ax.text(bar.get_x() + bar.get_width() / 2, value, f'{value:.1f}', ha='center', va='bottom')

        ax.set_title(title)
        ax.set_xlabel(xlabel)
        ax.set_ylabel(ylabel)

if __name__ == '__main__':
    app = QApplication(sys.argv)
    ex = Class()
    sys.exit(app.exec_())

---
